Product Description
You have selected the KERDI-DRAIN flange kit.
This kit includes:
1 drain with integrated bonding flange
4 inside and 2 outside KERDI-KERECK preformed waterproofing corners
1 KERDI-SEAL-PS pipe seal 3/4"
1 KERDI-SEAL-MV mixing valve seal 4-1/2"
Don’t forget! The KERDI-DRAIN grate kit must be selected separately.
Schluter®-KERDI-DRAIN is a floor drain specifically designed to allow connections to Schluter-KERDI or other load bearing bonded waterproof membranes. The membrane is adhered to the large integrated bonding flange to form a waterproof connection at the top of the drain assembly. KERDI-DRAIN consists of a drain casing and fully adjustable grate assembly or covering support to which tile is applied. The grate assembly accommodates a wide range of tile thicknesses and allows lateral and tilt adjustment as well. The covering support is placed flush with the tip of the bonding flange and can therefore accommodate any thickness tile covering.
